KYS5KW Series
PHOTOVOLTAIC ENERGY STORAGE ALL-IN-ONE(OUTDOOR)


Product Features

Modular Design

Modular design, strong expansibility, plug-in installation, integrated EMS smart energy management system



Smart Switch

Off grid operation, supporting emergency power supply and seamless switching



Wide voltage input range

Ultra-wide PV voltage range 120v-550v, battery ultra-wide voltage range 85v-220v



Safe and Reliable

IP68 intelligent air cooling, low temperature rise, long life time, built-in anti-lightning protection, high precision leakage protection



Smart and Easy Operation

Easy installation, supporting countercurrent function, supporting real-time remote monitoring and data checking



High power efficiency

Low power loss under high-temperature, improving power efficiency, DC over load capacity is as high as 1.3 times

Technical parameters
参数 KYS5kw-10kwh-O


Efficiency

MPPT.Efficiency 99.90%
Max.Efficiency >97.80%
Battery.Efficiency >98.10%


Battery Pack

Model KY-48V105AH
Serial Number 2
Cell Type Li-ion(LFP)
Battery Capacity(Ah) 105
Storage Capacity(KWh) 10
Available Capacity(KWh) 9.2
Voltage Range 75-106.5Vdc
Cycle Life 4000,90%DOD@25℃


PV Input

Max. PV input power(W) 7000
Max. PV input voltage(V) 550
MPP Operation Voltage Range(V) 120-550
Max. number of PV strings per MPPT 1/1
Max. PV input current(A) 12/12
Short-circuit current of PV input(A) 15/15


Battery Port

Operating Voltage Range(V) 85-450
Nominal Voltage(V) 96
Max Charge/Discharge Current(A) 25/25
Communication With BMS CAN


AC Input and Output

Rated Power(W) 5000
Max. Apparent AC Power(VA) 5000
Nominal AC Voltage(Vac) 230,1φ(L/N/PE)
AC Power Frequency(Hz) 50/60
Max. AC Output Current(A) 21.7
Power Factor Range ~1 (Adjustable from 0.8 leading to 0.8 lagging)
OutputTHDi(@Nominal Output) <3%


Off-Grid AC Output(Back-up ACOutput )

Rated Output Power(W) 5000
Max. Apparent AC Output Power(VA) 5000
Nominal AC Output Voltage(Vac) 230,1φ(L/N/PE)(N not connect to PE inside)
AC Power Frequency(Hz) 50/60
Max. AC Output Current(A) 21.7


Genaral Data

Operating Temperature Range -25℃ …+60℃(>45℃ derating)
Operating Altitude(m) <3000
Noise(dB) <40
Topology Transformerless
Cooling Method -Intelligent Fan
Ingress Protection Rating IP54
Relative Humidity 0-95%, no condensation
Display LCD
Communication With Portal RS485 (WiFi/GPRS Optinal)
Communication With Meter RS485
Dimensions (W*H*D)(mm) 686*500*1280


Certification

Safety IEC62109-1/-2
EMC EN61000-6-1/-2/-3,IEC61000
On-Grid standard AS4777.2,NRS097-2-1:2017
Transportation UN38.3
